Autodesk Identity Manager Component - version 1.2.77.0. Personal Accelerator for Revit 2023 - version 23.3.4.0. FormIt Converter for Revit 2023 - version 23.1.1.24. Generative Design for Revit - version 23.4.4.0. Cloud Models for Revit 2023 - version 23.1.1.24.
Steel Connections Core Content for Revit 2023 - version 23.1.1.24. See the Release Notes above for important help on install issues. Read the Autodesk Revit 2023.1 Update Release Notes This is a significant Revit 2023 Update with many enhancements and fixes. If you select drawing symbols of bars in accordance with a specified style, the symbols of bars are added to the reinforcement drawings (views and sections of the structure element).The Autodesk Revit 2023.1 Update is available via the Autodesk Desktop App or via download from the Autodesk subscription site. It is possible to select the reinforcement table type and its style in accordance with the settings defined in the Autodesk AutoCAD Structural Detailing - Reinforcement DWT file. Parameters related to generation of the reinforcement table and the symbols of bars in the created drawings of elements are available in the bottom part of the dialog. The description style defined in the program settings can be defined for bars and steel profiles. It is possible to select the description types, the method of presentation of the distribution bars and the description style for the bar distribution. Settings related to the description styles include separate parameters for different types of the presented reinforcement.
It is possible to define location of the bar distribution description and the leader type for single bars in the selection fields. It is possible to define distances between the descriptions and element edges (in the units used in the model). The settings related to the description location include separate parameters for the distribution of bars and for single bars.
The options parametrizing the description location and the description styles are available on tabs related to the specified element views. A selection list for selection of a structure element type (beam, column, spread footing, etc.) is located in the upper part of the dialog it defines for which element the reinforcement description will be defined.
